Custom Solutions

Customized slip rings and rotary unions to meet your needs.

Benefit from our many years of engineering experience in the areas of fluid and sealing technology as well as electrotechnical transmission technology. COSMAU offers custom designed components for specialized applications,our engineers work one-on-one with you and your team to design a custom rotary union & slip ring that best fits your needs — plus, we’re well known in the industry for our fast, efficient service.

QUALITY DESIGNS & CONSTRUCTION

The process behind our custom solutions begins with 3D generated design proposals and model supply. This provides for ease of product integration prior to manufacturing approval. You'll receive a custom design review and approval to finalize fit, mounting, and port locations.

OUR CUSTOM ROTARY UNIONS & SLIP RINGS FEATURE:

Slip Rings

Mounting flange

Direction of lead wire exits

Connectors and heat shrink tube

Lead wire length

Shield wire

Transmit combined high speed data

Customize for high temperature,shockproof environment

Combined with pneumatic,hydraulic

Customize high voltage,large current slip ring

IP65,IP68 Optional

Affordable price

Rotary Unions

Mounting flange

Through hole or solid design

up to 36 passages

Pressures up to 5000 psi

Variety of porting and connection size

Variety of seal combinations, materials, and coatings

Combined with electrical slip rings

Affordable price

  • COS19080201

    • Industry: Automation, IP65 waterproof
    • Size: 100mm ID, 185mm OD
    • Current: 8x 30A + 8x 5A
    • Speed: 100 RPM
    • Material: Al alloy

    COS19060208

    • Industry: Automation, IP68 waterproof
    • Size: 99mm OD
    • Current: 6x 10A + 12x 2A
    • Speed: 100 RPM
    • Material: Stainless steel

    COS19030115

    • Industry: Automation, IP65 waterproof
    • Size: 86mm OD
    • Current: 2x 1000M Etherent + 4x 10A
    • Speed: 200 RPM
    • Material: Al alloy

    COS19030205

    • Industry: Automation
    • Size: 38.1mm ID, 99mm OD
    • Current: 1x 1000M Etherent
    • Speed: 300 RPM
    • Material: Al alloy
  • COS19040402

    • Industry: Factory Automation
    • Flow passages: 6
    • Pressure: 0~50bar; Media: Water, Gas
    • Speed: 0~150 RPM
    • Material: Stainless steel shaft

    COS19120305

    • Industry: Heavy equipment
    • Flow passages: 4, G1/4
    • Pressure: 0~300bar; Media: Hydraulic Oil
    • Speed: 0~100 RPM
    • Material: Stainless steel shaft

    COS18070201

    • Industry: Marine
    • Flow passages: 4, G3/8, G3/4, G1
    • Pressure: 0~300bar; Media:Gas,Hydraulic Oil
    • Speed: 0~100 RPM
    • Material: All 316# stainless steel

    COS19050706

    • Industry: Heavy equipment
    • Flow passages: 4, G1, 150mm ID
    • Pressure: 0~50bar; Media:Gas, Water glycol
    • Speed: 0~40 RPM
    • Material: Carton steel
  • COS19120706

    • Industry: Heavy equipment
    • Flow passages: 2, G1/8
    • Pressure: 0~250bar; Media: hydraulic oil
    • Current: 2x 300A + 2x10A + 2x5A
    • Speed: 0~80 RPM
    • Material: Stainless steel shaft

    COS19110311

    • Industry: Factory automation
    • Flow passages: 1, G1/8
    • Pressure: 0~10bar; Media: Gas
    • Current: 6x 10A + 12x5A
    • Speed: 0~150 RPM, 50mm thru-bore
    • Material: Al alloy

    COS19100207

    • Industry: Factory automation, IP65
    • Flow passages: 4, G1/8
    • Pressure: 0~10bar; Media: Gas
    • Current: Power + signal + 1000M Ethernet
    • Speed: 0~100 RPM
    • Material: Al alloy

    COS19010308

    • Industry: Marine
    • Flow passages: 4, G3/8, G3/4, G1
    • Pressure: 0~300bar; Media:Gas,Hydraulic Oil
    • Current: Power + signal + RG59 coaxial
    • Speed: 0~80 RPM
    • Material: All 316# stainless steel
